LEDCOMPASS16

ORDER CODE: LEDCOMPASS16

Main features:

---

LEDCOMPASS16 is a LED module for the creation of ledscreens with 16,76mm pixel pitch, ideal for video screening, pictures and backgrounds for medium viewing distances from ledwall surface.
The architecture of LEDCOMPASS16 is conceived with 1200x600 mm module size, featuring 2592 SMD FullColor LEDs for an impressive light output up to 2700NIT.
The module design is completely made in aluminum and the on-board mechanics allow the mounting in curve-shape configurations (+/- 18° per module).
IP65 protection rate on front side makes LEDCOMPASS16 suitable also for temporary outdoor application.
With a transparency factor of 25%, LEDCOMPASS16 allows the light to go through the screen surface, opening up a wide range of creative design possibilities, combining video screening with backlights through washlight and beam projectors, even for 3D projections.
The main structure is designed in aluminum, making LEDCOMPASS16 extremely lightweight (only 22,9 kg/m2), allowing a wide flexibility in configuration, also in hanging applications, with no limits of weight.

Applications

• In concerts and live events, where heavy large-size screen would overload the supporting structure
• In TV Studios for multiple viewing angle
• Wide-canvas dynamic backdrops for theatres and TV studios combined with lighting effects
• Touring and Live event for Camera streaming
• Large trade-show booths with creative video imaging
• In theme parks or public events

Mechanical architecture

• Module dimensions (WxHxD): 600x1200x66 mm
• Module weight: 16.500 g
• Weight per square meter: 22,9 kg
• LED housing bar in aluminum
• Transparency rate: 25%
• Main structure in steel
• Curvability: +/- 18° each module
• Mechanical finishing: black
• Cooling: natural airflow
• Working position: every orientation
• Vertical hanging system: built-in aliscaf clamp support

Electrical features

• Power supply: AC 110/230V 50/60Hz
• Power IN connections: Neutrik Powercon
• Max power consumption (module): 500W
• Average power consumption (module): 400W
• Max power consumption (per square meter): 690W
• Power output: Max 4 modules
• MTBF: > 1.000 h
• Working temperature: -10/50 °C
• Max ambience humidity: 10% - 90%

Video features

• LED source: high-power SMD FullColor
• Module resolution: 36x72 pixel, 2592 total pixel
• Pixel pitch: 16,76mm
• LED density: 3600 LED/sqm
• Luminous flux: 2.700 cd/sqm (NIT)
• LED life span: >50.000h
• Colours: >68,7 billions through RGB mixing
• Grayscale: 12bit
• Refresh rate: >1000Hz
• Colour calibration through PC software
• Maximum video IN signal resolution: 1024x768; 1920x1080 pixel
• Viewing angle: 140° horizontal, 140° vertical
• Dead pixel ratio: <0,002

Control system

• Dedicated interface (Sender box) for video signal distribution and screen configuration
• Data IN sender box: USB connector
• Data IN module: RJ45 connectors
• Connection between screen and sender box: USB cable
• Connection between sender box and videowall: CAT5 data cable + Ethercon Neutrik connectors
