MPC250A
PROAUDIO

MPC250A

ORDER CODE: MPC250A

MPC250A is a multi-purpose stereo amplifier with multi-media player which can be used both for 70V constant voltage systems (1 ch in a bridge) that for 4/8 Ohm low impedance systems (2 ch stereo).

Main features:

  • It is equipped with MP3 media player/Bluetooth.
  • It is designed for permanent or mobile installations where easy control of music is important (eg. restaurants, gyms stores).
  • MPC250A offers digital playback from SD cards or USB sticks.
  • The MPC250A amplifier provides full MP3 playback control, microphone input (XLR / 1 / 4 combo), 5 inputs (RCA / jack 3.5) and the master volume control of high and low tones. Moreover, the output line (RCA) allows you to connect an additional amplifier.

PHOTO GALLERY

Technical specifications

AMPLIFIED MIXER
  • Channels: 2
  • Circuit class: digital
OUTPUT
  • Single channel power: 250/300 8/4 Ohm
  • Bridge mode power: 600 8 Ohm
  • Power at constant voltage 70 V: 600W (bridge mode)
AUDIO SPECIFICATIONS
  • Frequency responce: 20 - 20000Hz @ 8 Ohm (±0.5 dB)
  • THD+N: <0.1%
  • Input impedance: 10kΩ unbalance
  • Signal/Noise rate: >100dB
POWER SUPPLY STAGE
  • Type: Switching
  • Operating voltage/frequency: 230V (+/- 5%) 50Hz
PROTECTIONS
  • Output: Soft-start, short circuit, DC, overheat
FUNCTIONS
  • Media player: MP3/USB/SD/Bluetooth
  • Tone controls output: 100 Hz, 10kHz (±12dB)
  • Input volume control: mic, line1/2/3/4/aux
  • Output volume control: output master
INPUT/OUTPUT CONNECTORS
  • Input signal: XLR combo (mic), pin RCA, Jack 3.5 mm
  • Output signal: binding post
  • Power connection: VDE
PHYSICAL
  • Cooling: forced air with fan
  • Dimensions (WxHxD): 485x44x212mm / 19.09''x1.73''x8.35''
  • Rack unit: 1
  • Weight: 2.3kg / 5.07lbs

Versions

Accessories & Related Products

    DOWNLOAD

    Data sheet & specs

    File name File size Download

    User manual

    File name File size Download
    User manualMpc250a_USER_MANUAL.pdf1MB

    DMX chart & personalities

    File name File size Download

    Photometrics

    File name File size Download

    CAD symbols & drawings

    File name File size Download

    Tech docs

    File name File size Download

    Software

    File name File size Download

    Firmware
