SETSAC3MPB
SEETRONIC

SETSAC3MPB

ORDER CODE: SETSAC3MPB

3-pole panel male connector, silver (line, neutral, ground) with unified size D-type frame to power devices that need a robust solution and a quick and safe "Quick lock" locking system.
Attention: the connector is not designed for "hot" connection, so it is not recommended to connect or disconnect devices under load!

Main features:

  • Locking device: Quick Lock.
  • Lifetime: > 1000 mating cycles.
  • Contacts. Copper, silver-plated.
  • Shell: Polyamide.
  • UL recognized components.
  • Safety requirements: IEC 61984.
  • Flammability class: UL94 V-0.
  • Temperature range: from -30 °C to +80 °C.
  • Dimensions (WxHxD): 26x31x37 mm.

PHOTO GALLERY

Technical specifications

Versions

Accessories & Related Products

SETCNACMPAB
SETCNACMPAB
(Optional)
Protective rubber cover for SETSAC3MPA-N-W / SETSAC3MPB-N-W

DOWNLOAD

Data sheet & specs

File name File size Download

User manual

File name File size Download
User manualSetsac3mpb_USER_MANUAL.pdf104KB

DMX chart & personalities

File name File size Download

Photometrics

File name File size Download

CAD symbols & drawings

File name File size Download
2DSetsac3mpb_CAD_2D.dwg486KB
Technical drawingSetsac3mpb_TECHNICAL_DRAWING.pdf57KB
