ECLPENDANTS
PROLIGHTS

EclPendant S new

50W single color House light with passive cooling

The EclPendant S merges elegant design with cutting-edge, eco-friendly technology, ensuring optimal illumination for any venue. This series of pendant lights offers a diverse range of LED sources, including options in RGB + Warm White, Variable White and single color (3000K, 4000K and 5600K), each featuring a 50 Watt LED that provides high-quality light output, uniform color, and remarkable durability.

Completed by a wide range of optics, accessories, and versatile mounting solutions, the EclPendant S adapts to various installation needs. Mounting alternatives include pendant, surface, stem, wall, adjustable bracket, and recessed options. It can be directly wired to mains power (100-240 VAC or 48 VDC) and integrates seamlessly with control protocols like DMX + RDM and DALI, thanks to its accessible terminal blocks.

User-friendly settings are manageable via the unit's onboard GUI, enhancing its functionality. The fixture's wide array of optics and accessories is designed for utmost flexibility and precision, allowing easy on-site changes without complications.

Notably, the EclPendant S features a fan-free thermal design, ensuring quiet operation while delivering consistent and robust lumen output throughout its extended lifespan.



* Please note: The hanging bracket is not included with the product.

5 YEARS WARRANTY

Main features:

  • House light with 50W 3000K, 4000K and 5600K LED source with passive cooling
  • 100-240 VAC or 48 VDC power input. Control via DALI, DMX, RDM
  • Extensive mounting option, optics and accessories available

PHOTO GALLERY

Technical specifications

LIGHT SOURCE
  • Source: 50W COB LED
  • CCT: 3000K (TU), 4000K (NW), 5600K (DY)
  • Luminous flux: (TU) 2'814 lm; (NW) 3'851 lm; (DY) 4'045 @full
  • Lux: (TU) 796 lx; (NW) 1'079 lx; (DY) 1'116lx @5 m full
  • CRI: (TU) 98,1; (NW) 95,3; (DY) 95,2
  • R9: (TU) 91,8; (NW) 89,2; (DY) 91,8
  • TLCI: (TU) 98; (NW) 96; (DY) 96
  • TM30 Rf: (TU) 93,4; (NW) 92,3; (DY) 90,9
  • TM30 Rg: (TU) 99,1; (NW) 101,3; (DY) 100,8
  • Source life expectancy: > 50.000 hrs (L70B10 @Ta 25° C / 77° F)
OPTICS
  • Beam angle: 20°
  • Field angle: 40°
  • Lens diameter: 100mm / 3.94''
  • Lens type: fresnel lens
  • Other: see available accessories
DYNAMIC EFFECTS
  • Static mode: selection of static dimmer
  • Manual mode: manual adjustment of dimmer and strobe
  • Auto mode: built-in programs with execution speed adjustment
BODY
  • Body: sturdy die-cast aluminium body
  • Body colour: RAL 9004 or RAL 9010
CONTROL
  • Protocols: DALI Type6, DMX512, RDM
  • DMX channels: UNO / DUO / Standard / Extendedchannel
  • Wireless Control: optional, LumenRadio Timo Fx DMX/RDM compatible with both CRMX (Lumen Radio) and W-DMX (Wireless DMX) (Order code SP018409)
  • RDM: RDM for remote monitoring and settings
  • Display: Graphic User Interface
  • Firmware upgrade: yes, via USB - DMX interface (UPBOXPRO/UPBOX1) not included
  • Other: 16bit control of dimmer
ELECTRONICS
  • Dimmer: linear 0 ~ 100% electronic dimmer
  • Dimmer curves: 4 selectable dimming modes available
  • Strobe / shutter: 1-30 Hz, electronic
  • Operating temperature: -10° ~ +45°
  • LED Control: flicker free frequency with adjustable PWM
  • Selectable PWM: 600 ~ 40.000 Hz
ELECTRICAL
  • Mains power supply: 100-240V - 50/60Hz
  • Low Voltage DC mains: DC 48V for emergency light use
  • Max power consumption: 60W
  • Output (at 230V): 24 units on a single power line
  • Power factor: > 0,93
PHYSICAL
  • IP rating: 20
  • Cooling: Heatsink with heat pipes, passive cooling and fan-free
  • Suspension and fixing: bracket for hanging and positioning (bracket not included on the product)
  • Signal connection: Screw terminal block
  • Power connection: Screw terminal block
  • Dimensions (WxHxD): 135x300x135mm / 5.31''x11.81''x5.31''
  • Weight: 3kg / 6.61lbs
CERTIFICATIONS / APPROVALS
  • Certifications / Approvals: CE, RCM, FCC, cTUVus
BOX CONTENT

Versions

Code
CCT
Finishing
ECLPENDANTSTUBK
ECLPENDANTSTUBK (NEW)
TU - 3000K
black
ECLPENDANTSNWBK
ECLPENDANTSNWBK (NEW)
NW - 4000K
black
ECLPENDANTSDYBK
ECLPENDANTSDYBK (NEW)
DY - 5600K
black
ECLPENDANTSTUWH
ECLPENDANTSTUWH (NEW)
TU - 3000K
white
ECLPENDANTSNWWH
ECLPENDANTSNWWH (NEW)
NW - 4000K
white
ECLPENDANTSDYWH
ECLPENDANTSDYWH (NEW)
DY - 5600K
white

Accessories & Related Products

ECLPENDSLENS20
ECLPENDSLENS20
(included)
ECLPENDANTS series 20° lens
ECLPENDSLENS40
ECLPENDSLENS40
(optional)
ECLPENDANTS series 40° lens
ECLPENDSLENS60
ECLPENDSLENS60
(optional)
ECLPENDANTS series 60° lens
ECLPENDSHGBRKBK
ECLPENDSHGBRKBK
(optional)
Hanging bracket for ECLPENDANTS series, black
ECLPENDSHGBRKWH
ECLPENDSHGBRKWH
(optional)
Hanging bracket for ECLPENDANTS series, white
ECLPENDSRECSKITBK
ECLPENDSRECSKITBK
(optional)
Ceiling recessed kit for ECLPENDANTS series, black
ECLPENDSRECSKITWH
ECLPENDSRECSKITWH
(optional)
Ceiling recessed kit for ECLPENDANTS series, white
ECLPENDSHSNOOTBK
ECLPENDSHSNOOTBK
(optional)
Half snoot for ECLPENDANTS series, black
ECLPENDSHSNOOTWH
ECLPENDSHSNOOTWH
(optional)
Half snoot for ECLPENDANTS series, white
ECLPENDSFSNOOTBK
ECLPENDSFSNOOTBK
(optional)
Full snoot for ECLPENDANTS series, black
ECLPENDSFSNOOTWH
ECLPENDSFSNOOTWH
(optional)
Full snoot for ECLPENDANTS series, white
ECLPENDSHLOUVREBK
ECLPENDSHLOUVREBK
(optional)
Honeycomb louvre for ECLPENDANTS series, black
ECLPENDSHLOUVREWH
ECLPENDSHLOUVREWH
(optional)
Honeycomb louvre for ECLPENDANTS series, white
ECLPENDSCLOUVREBK
ECLPENDSCLOUVREBK
(optional)
Concentric louvre for ECLPENDANTS series, black
ECLPENDSCLOUVREWH
ECLPENDSCLOUVREWH
(optional)
Concentric louvre for ECLPENDANTS series, white
ECLPENDSBDBK
ECLPENDSBDBK
(optional)
Barndoor with 4 directional flaps to adjust the light beam for ECLPENDANTS,black
ECLPENDSBDWH
ECLPENDSBDWH
(optional)
Barndoor with 4 directional flaps to adjust the light beam for ECLPENDANTS,white
ECLPENDSCEILKITBK
ECLPENDSCEILKITBK
(optional)
Ceiling-mounted kit (surface) for ECLPENDANTS series, black
ECLPENDSCEILKITWH
ECLPENDSCEILKITWH
(optional)
Ceiling-mounted kit (surface) for ECLPENDANTS series, white
ECLPENDWALLBRKBK
ECLPENDWALLBRKBK
(optional)
Wall mounting bracket for ECLPENDANT series, black
ECLPENDWALLBRKABK
ECLPENDWALLBRKABK
(optional)
Ring adapter for ECLPENDWALLBRK (not included), black
ECLPENDWALLBRKWH
ECLPENDWALLBRKWH
(optional)
Wall mounting bracket for ECLPENDANT series, white
ECLPENDWALLBRKAWH
ECLPENDWALLBRKAWH
(optional)
Ring adapter for ECLPENDWALLBRK (not included), white
TOUR53415L03
TOUR53415L03
(optional)
Dmx cable HC5340. CANC5MXX XLR 5p->CANC5FXX XLR (f) 5p, L.3m
C6002B
C6002B
(optional)
Slim aluminum clamp, 200kg loading, 48-51mm tubes, M10 bolt, Black&White& White
RSR0630B
RSR0630B
(optional)
Steel security cable for hanging bodies, inox steel shackle, L=60 cm, black
9533FXWL03
9533FXWL03
(optional)
Ass. 3x2.5mm TH07 cable, SCHUKO plug, MENAC3FXW socket, L.3m
9513FXWL03
9513FXWL03
(optional)
Ass. 3x2.5mm TH07 cable, 16A 3p 230V CEE plug, MENAC3FXW socket, L.3 m
958225L03
958225L03
(optional)
3x2.5mm TH07 Cable, 16A 3p PwCon MXW, 16A 3p PwCon FXW, L. 3m
PLCPW93075
PLCPW93075
(optional)
Power PVC cable H05VV-F 3G0,75, 1 meter lenght
PLCDX53D5
PLCDX53D5
(optional)
120 Ohm DMX cable, 2 twisted poles, external sheath with reduced diameter, 1 m
PLCPD7501P14D
PLCPD7501P14D
(optional)
Power & DMX 120 Ohm, 1 meter length, not suitable for track adapter connection
PLCPD7501P68D
PLCPD7501P68D
(optional)
Power & DMX 120 Ohm
PLCYA7501P14D
PLCYA7501P14D
(optional)
YY splitter cable Power 3x0.75 mm2 + 5p IN/OUT DMX 120 Ohm, bare end, 1 meter
UPBOXPRO
UPBOXPRO
(optional)
Firmware uploader kit, USB IN, 5-pin XLR DMX OUT connector

DOWNLOAD

Data sheet & specs

User manual

DMX chart & personalities

File name File size Download
DMX chartEclpendantsnwbk_DMX_CHARTS.pdf100KB
ECLPENDANTSTUBK Firmware rev. 1.1.01.0
manufacturer fixture library (Link) Link
manufacturer fixture library (Link) Link
manufacturer fixture library (Link) Link
manufacturer fixture library (Link) Link
manufacturer fixture library (Link) Link
manufacturer fixture library (Link) Link
ECLPENDANTSNWBK Firmware rev. 1.1.01.0
manufacturer fixture library (Link) Link
manufacturer fixture library (Link) Link
manufacturer fixture library (Link) Link
manufacturer fixture library (Link) Link
manufacturer fixture library (Link) Link
manufacturer fixture library (Link) Link
ECLPENDANTSDYBK Firmware rev. 1.1.01.0
manufacturer fixture library (Link) Link
manufacturer fixture library (Link) Link
manufacturer fixture library (Link) Link
manufacturer fixture library (Link) Link
manufacturer fixture library (Link) Link
manufacturer fixture library (Link) Link

Tech docs

File name File size Download
Noise ReportEclpendants_NOISE_REPORT.pdf577KB

Software

File name File size Download

Firmware


Firmware update instructions

1 Download the firmware (only the latest version is available - contact support@prolights.it for more info)

2 Download the updater software UpBox_Tool

3 Follow the instructions in the following guide
-------------------------------------------------------------------------------
Notes:
  • Firmware updates require the UPBOXPRO compatible with all Prolights products
  • It's possible to use UPBOX1 and UPBOX2 *DISCONTINUED* checking the compatibility in the below tab
  • UpBox_Tool  software is compatible with all UPBOX interfaces
  • To update NET boards with .EHEX files a network cable and Professional Uploader software it's needed. It's possible to follow this guide
Update Tool: UPBOXPRO UPBOXPRO
Check hardware changelog before downloading firmware
Revision Release date Firmware changelog HW Compatibility
1.1.01.0 STABLE 27/06/2024 Fixed Bug:
  • Device freezes every time you enter the Information/Wireless Quality menu. A reboot is required.
Rev. 1.0
Update Tool: UPBOXPRO UPBOXPRO
Check hardware changelog before downloading firmware
Revision Release date Firmware changelog HW Compatibility
1.1.01.0 STABLE 27/06/2024 Fixed Bug:
  • Device freezes every time you enter the Information/Wireless Quality menu. A reboot is required.
Rev. 1.0
Update Tool: UPBOXPRO UPBOXPRO
Check hardware changelog before downloading firmware
Revision Release date Firmware changelog HW Compatibility
1.1.01.0 STABLE 27/06/2024 Fixed Bug:
  • Device freezes every time you enter the Information/Wireless Quality menu. A reboot is required.
Rev. 1.0
Update Tool: UPBOXPRO UPBOXPRO
Check hardware changelog before downloading firmware
Revision Release date Firmware changelog HW Compatibility
1.1.01.0 STABLE 27/06/2024 Fixed Bug:
  • Device freezes every time you enter the Information/Wireless Quality menu. A reboot is required.
Rev. 1.0
Update Tool: UPBOXPRO UPBOXPRO
Check hardware changelog before downloading firmware
Revision Release date Firmware changelog HW Compatibility
1.1.01.0 STABLE 27/06/2024 Fixed Bug:
  • Device freezes every time you enter the Information/Wireless Quality menu. A reboot is required.
Rev. 1.0
Update Tool: UPBOXPRO UPBOXPRO
Check hardware changelog before downloading firmware
Revision Release date Firmware changelog HW Compatibility
1.1.01.0 STABLE 27/06/2024 Fixed Bug:
  • Device freezes every time you enter the Information/Wireless Quality menu. A reboot is required.
Rev. 1.0

Info Request

News

November 20, 2024
PROLIGHTS lights up the Despotovac Cultural Centre
PROLIGHTS lights up the Despotovac Cultural Centre
November 18, 2024
Hotel National Chooses PROLIGHTS for New Stage Lighting Setup
Hotel National Chooses PROLIGHTS for New Stage Lighting Setup
November 11, 2024
PROLIGHTS Illuminates the WWE Experience in Riyadh
PROLIGHTS Illuminates the WWE Experience in Riyadh
November 07, 2024
ICOONTheatre shines with PROLIGHTS
ICOONTheatre shines with PROLIGHTS
November 04, 2024
Intense Lighting Expands Inventory with PROLIGHTS EclProfile CT+
Intense Lighting Expands Inventory with PROLIGHTS EclProfile CT+
October 28, 2024
PROLIGHTS Illuminates the Karol Szymanowski Academy of Music in Katowice
PROLIGHTS Illuminates the Karol Szymanowski Academy of Music in Katowice
October 21, 2024
NRK Chooses PROLIGHTS for the New Lighting Setup in Studio 5 of Dagsrevyen
NRK Chooses PROLIGHTS for the New Lighting Setup in Studio 5 of Dagsrevyen
October 18, 2024
Centrestate Sound & lighting choose PROLIGHTS Smart BatWash
Centrestate Sound & lighting choose PROLIGHTS Smart BatWash
October 15, 2024
PROLIGHTS lights up season 13th of Masterchef Poland
PROLIGHTS lights up season 13th of Masterchef Poland
October 11, 2024
PROLIGHTS lights up the final bouts of No Limit Boxing with EclPanel TWC
PROLIGHTS lights up the final bouts of No Limit Boxing with EclPanel TWC
October 08, 2024
Gotcha AV expands catalogue with PROLIGHTS
Gotcha AV expands catalogue with PROLIGHTS
October 04, 2024
PROLIGHTS lights up the Great Hall of the Historic Town Hall in Košice
PROLIGHTS lights up the Great Hall of the Historic Town Hall in Košice

Subscribe to our Newsletter

Loading...
