V575WASH
PROLIGHTS
discontinued

V575WASH

ORDER CODE: V575WASH

Main features:

    Lamp
    • Philips 575W 95V MSD/MSR575 (cod. 800144 included)
    • Socket: GX9,5
    • Colour temperature: 7000 K
    • Luminous flux: 49.000 lm
    • Average life: 1000 h

    Optics
    • High efficiency optical system
    • Fresnel lens: 150 mm diameter
    • Parabolic aluminium with elliptical profile
    • Zoom: electromechanical linear zoom 11-28°

    Dimmer / shutter / strobe
    • 0-100% linear dimmer
    • Independent shutter and fading effects with adjustable speed
    • Strobe: mechanical, 10 flash per second

    Colour system
    • Advanced CMY colour mixing obtained by 3 dichroic filters cyan, magenta, yellow
    • Additional colour wheel with 6 dichroic filters + open (linear-stepless selection)
    • Bidirectional rainbow effect and Macro preset
    • Frost filter to increase light-beam aperture; adjustable positioning "banana" effect
    • Easy calibration and maintenance by magnetic repositioning
    • Colour change with synchronized blackout
    • Easy show: built-in programs with automatic/sound activated mode enabled by LED control panel or by EC800 remote control (not included)

    Electronics
    • User Interface: 4-digit multi-function LED display to control unit addressing, general settings and fixture life timer
    • 2 DMX available configurations: 8 channels (8 bit) and 16 channels (16 bit) for full flexibility of control
    • Input and output signal through XLR 3p connector
    • Lamp On/Off: through control panel or via DMX
    • Unit reset: through control panel or via DMX
    • Electronic self-test and check-up for diagnostics
    • Cooling: forced air, protection against overheating. Fan speed control for quieter operation

    Structure and moving body
    • Aluminium structure with die-cast polymer cover, black colour
    • Ergonomic side handles for transportation
    • Motion Angle: Pan = 540° Tilt = 270°
    • Pan/Tilt resolution: 8-bit or 16-bit
        Pan = 2,10° Pan Fine = 0,008°    Tilt = 1,05° Tilt Fine = 0,004°
    • Feedback automatic repositioning
    • Suspension and fixing: any possible working position through omega kit (included) with “quick lock” system

    Power supply
    • Electromagnetic ballast: 200-240V 50/60Hz universal power supply
    • Power consumption: 800W

    Weight and dimensions
    • Weight: 30 kgs
    • Dimensions (WxHxD): 425x570x380 mm
