ALS34
ORDER CODE: ALS34
Share me

Immagine Principale
  • ALS34
  • ALS34
  • ALS34
  • Code Tube (mm) Diagonal (mm) W (cm) H (cm) D (cm) Weight (kg) Volume (mc) Avail.
    ALS34050
    50x2 20x2 50 29 29 3,50 0,042
    ALS34100
    50x2 20x2 100 29 29 5,60 0,084
    ALS34150
    50x2 20x2 150 29 29 8,30 0,126
    ALS34200
    50x2 20x2 200 29 29 10,60 0,168
    ALS34250
    50x2 20x2 250 29 29 12,80 0,210
    ALS34300
    50x2 20x2 300 29 29 14,20 0,252
    ALS34350
    50x2 20x2 350 29 29 17,50 0,294
    ALS34400
    50x2 20x2 400 29 29 18,60 0,336
    ALS34450
    50x2 20x2 450 29 29 20,90 0,378
    ALS34500
    50x2 20x2 500 29 29 23,0 0,421

    Square section aluminium truss with 29 cm sides

    Features:
    Lengthwise: extruded tubes, Ø 50x2 mm 6082 T6
    Diagonal: extruded tubes, Ø 20x2 mm 6082 T6
    Plate: cast aluminium plate
    Fast connection kit ALFCQ5 included

    ITEMS REF.
    Accessory Code
    Description
    ALS34 (optional)
    Aluminium floor plate for square section trusses ALH34/ALS34 series.
    ALS34 (optional)
    {CODEs}ALS34K80
    DISCONTINUED
    *6 way DADO module, ALS34 series compatible, 2x ALFCQ5K8 included
    ALS34 (optional)
    {CODEs}ALS34L29
    DISCONTINUED
    *2-way L corner for ALS34 Series, extrude tube 50x2mm, 2x ALFCQ5 included
    ALS34 (optional)
    {CODEs}ALS34L30
    DISCONTINUED
    *3-way L corner for ALS34 Series, extrude tube 50x2mm, 2x ALFCQ5 included
    ALS34 (optional)
    {CODEs}ALS34T30
    DISCONTINUED
    *3-way T joint for ALS34 Series, extrude tube 50x2mm, 2x ALFCQ5 included
    ALS34 (optional)
    {CODEs}ALS34T40
    DISCONTINUED
    *4-way T joint for ALS34 Series, extrude tube 50x2mm, 2x ALFCQ5 included
    ALS34 (optional)
    {CODEs}ALS34X40
    DISCONTINUED
    *4-way X joint for ALS34 Series, extrude tube 50x2mm, 2x ALFCQ5 included
