ARK1200SA
DAD

ARK1200SA

Active subwoofer, LF 600W, MF+HF 2x300W/4 Ohm, 121dB SPL

Active sub woofer 600W with 2x300W/4Ohm stereo output.

Main features:

  • Adjustable Crossover: LPF:80/120 Hz - HPF 22, 80,125 Hz
  • Can be used with full range speakers in the ARK series.
  • Possible combinations ARK1200SA + 1 to 4 speaker of AIR or ARK series (16Ohm) for each channel.

PHOTO GALLERY

Technical specifications

LOUDSPEAKER
  • System type: active subwoofer with amplified stereo out
COMPONENTS
  • Low frequency: 2x8'' woofer/2''v.c.
  • Built-in amp: LF 600+MF/HF 2x300 W (Continuous Power - EIA 1 kHz 1% THD)
ACOUSTICAL SPECIFICATIONS
  • SPL cont/peak: 120/126dBdB @1m (free field)
  • Frequency response: 40/200Hz (±3dB)
  • Coverage angle HxV: ° omnidirectional
ELECTRONICS SPECIFICATIONS
  • Amplifier: Digital
  • Power: 600+2x300W /4Ohm
  • Input sensitivity: 4 dBu (1,228Vrms) adjustable
  • Protection: limiter temp.
  • User controls: mic, line, master, eq LF-HF
  • Operating voltage/frequency: 220 V~240 V/50 Hz
INPUT/OUTPUT CONNECTORS
  • Input signal: XLR IN/OUT, jack 6.35 mm, pin RCA unbal.
  • Output signal: 2 x 4 pole
  • Power connection: powerCON IN/OUT
CABINET CONSTRUCTION
  • Cabinet material: 15mm / 0.59'' plywood
  • Sospension system: wall brackets (included)
PHYSICAL
  • Dimensions (WxHxD): 500x246x325mm / 19.69''x9.69''x12.8''
  • Weight: 14.5kg / 31.97lbs

Versions

Code
Finishing
ARK1200SABK
ARK1200SABK
Black
ARK1200SAWH
ARK1200SAWH
White

Accessories & Related Products

    DOWNLOAD

    Data sheet & specs

    File name File size Download

    User manual

    File name File size Download
    User manualArk1200sa_USER_MANUAL.pdf6MB

    DMX chart & personalities

    File name File size Download

    Photometrics

    File name File size Download

    CAD symbols & drawings

    File name File size Download
    2DArk1200sa_CAD_2D.dwg242KB
    Technical drawingArk1200sa_TECHNICAL_DRAWING.pdf73KB

    Tech docs

    File name File size Download

    Software

    File name File size Download

    Firmware
