IPTESTBOX
PROLIGHTS

IPTESTBOX

ORDER CODE: IPTESTBOX

Portable vacuum and pressure tester with air compressor for Prolights IP fixtures

IPTESTBOX is a portable tool coming into an ABS case that is capable to test IP rating for multiple PROLIGHTS products. The tool features features both vacuum (sucking the air) and pressure (pushing hair) test of the lighting fixtures through the internal air compressor, monitoring the pressure behaviour inside the unit housing according to the IP class or product selected.
IPTESTBOX is simple to use, just unscrew the IP air vent valve on the product and connect the IP tester air-duct cable, replace the other valve with a supplied adapter, press a button and wait for the result.

Main features:

  • Test according to a specific PROLIGHTS product program, or according to an IP class
  • Continuous stress test mode with multiple cycles
  • Save and load report from SD card
  • Generating reports with fixture name, serial number and date/time of test
  • Report readable in CSV format
  • Import/Export settings
  • Unit Auto test for self diagnostic of the IPTESTBOX
  • Firmware upgrade through SD card
See variants

PHOTO GALLERY

IPTESTBOX
IPTESTBOX
IPTESTBOX
IPTESTBOX

Technical specifications

BODY
  • Body: Sturdy ABS case
  • Body colour: RAL 9004
CONTROL
  • Display: Graphic User Interface
  • Firmware upgrade: via menu with internal SD Card memory
ELECTRONICS
  • Operating temperature: -20° C / +45° C (-4° F / +113° F) Ta
ELECTRICAL
  • Mains power supply: 100-240V - 50/60Hz
  • Max power consumption: 40W
PHYSICAL
  • Power connection: Neutrik powerCON TRUE1 IN connector
  • Dimensions (WxHxD): 420x362x165mm / 16.54''x14.25''x6.5''
  • Weight: 7kg / 15.43lbs
BOX CONTENT

Versions

Accessories & Related Products

IPTBM6ADP
IPTBM6ADP
(Included)
M6 adapter and M6 cap for IPTESTBOX
958225L03
958225L03
(Optional)
3x2.5mm TH07 Cable, 16A 3p PwCon MXW, 16A 3p PwCon FXW, L. 3m
9513FXWL03
9513FXWL03
(Optional)
Ass. 3x2.5mm TH07 cable, 16A 3p 230V CEE plug, MENAC3FXW socket, L.3 m
9533FXWL03
9533FXWL03
(Optional)
Ass. 3x2.5mm TH07 cable, SCHUKO plug, MENAC3FXW socket, L.3m

DOWNLOAD

Data sheet & specs

File name File size Download

User manual

File name File size Download
User manualIptestbox_USER_MANUAL_EN.pdf2MB

DMX chart & personalities

File name File size Download

Photometrics

File name File size Download

CAD symbols & drawings

File name File size Download
2DIptestbox_CAD_2D.dwg1MB
Technical drawingIptestbox_TECHNICAL_DRAWING.pdf215KB

Tech docs

File name File size Download

Software

File name File size Download

Firmware


Firmware update instructions

1 Download the firmware (only the latest version is available - contact support@prolights.it for more info)

2 Download the updater software UpBox_Tool

3 Follow the instructions in the following guide
-------------------------------------------------------------------------------
Notes:
  • Firmware updates require the UPBOXPRO compatible with all Prolights products
  • It's possible to use UPBOX1 and UPBOX2 *DISCONTINUED* checking the compatibility in the below tab
  • UpBox_Tool  software is compatible with all UPBOX interfaces
  • To update NET boards with .EHEX files a network cable and Professional Uploader software it's needed. It's possible to follow this guide
Update Tool: {Upbox}
Check hardware changelog before downloading firmware
Revision Release date Firmware changelog HW Compatibility
2.1.07 STABLE 27/12/2023 Improvement:
  • Improved the menu structure and its graphical interface.
FIRMWARE UPDATE PROCEDURE:
  • Create a folder renamed "firmware" on the computer with the .prl file inside ;
  • Insert SD Card on the computer and formatting it in FAT32 ;
  • Copy "firmware" folder from computer to SD Card ;
  • Insert SD Card into IPTESTBOX, turn on the device in bootloader (UP+ENTER when turning on), select the file 1U1.prl and press Enter to start the firmware update.
Notes:
  1. SD Card cannot have a memory larger than 32GB as it will not be possible to format it in FAT32.
  2. If you have an SD Card larger than 32GB (exFAT), you need to create a partition inside it up to 32GB in order to format it in FAT32.
