LDST2408
ORDER CODE: LDST2408
Share me

Immagine Principale
  • LDST2408
  • LDST2408
  • LDST2408
  • LDST2408
  • LDST2408
  • LDST2408
  • LDST2408
  • LDST2408
    • Code Length (mt) IN XLR (on drum) OUT XLR (on drum) OUT XLR (on cable) IN XLR (on cable) Avail.
    LDST2408L30 30 24 (CAX300FP) 8 (CAX300MP) 24 (CAX300MV) 8 (CAX300FV)
    LDST2408L45 45 24 (CAX300FP) 8 (CAX300MP) 24 (CAX300MV) 8 (CAX300FV)

    Splitter stage box, 24 IN / 8 OUT XLR, with splitter cable included.

    Features:
    Multipair panel plug for splitting the signal to stage mixer.
    Audio transformers (1:1 ratio) on each channel.
    Splitter cable with multipair socket and XLR 3p connectors, 5m length.
    Assembled with ACM400 multi-core cable, separately shielded and sheathed pairs.
    Numbered 3 poles XLR connectors.
    Assembled on cable drum with wheels.
    Body in hi-resistant steel.
    Matte black finish.

    ITEMS REF.
    Accessory Code
    Description
    LDST2408 (optional)
    LDST3208 (optional)
    LD2408 (optional)
    LD3208 (optional)
    {CODEs}FCAR22
    End of life
    Flight case for LD/LDS series stage box, skate incl., (WxHxD) 710x610x520m
